Description
Printing Technology
MEMO: This unit and the P600 Epson Printers are no longer produced or available if you’re or Looking for a Printer and software for your screen printing business and films? Call us, we have a solution that works with any printer and no special inks are needed.
Advanced MicroPiezo® AMC™ print head with ink-repelling coating technology, 8-channel, drop-on-demand, inkjet print head
Nozzle Configuration: 180 nozzles x 8
Minimum Ink Droplet Size:
3.5 picoliters
Variable Droplet Technology can produce up to 3 different droplet sizes per print line
Maximum Print Resolution: 2880 x 1440 dpi
Maximum Printable Area:
Maximum paper width: 17″
Maximum cut-sheet size: 17″ x 22″
Minimum cut-sheet size: 3.5″ x 5″
Maximum printable area: 17″ x 129″
Paper Handling
Maximum Paper Size:
Main top-loading feeder
Up to 17″ x 22″
Up to 120 sheets plain; 30 photo
Roll paper (optional)
17″ roll, 2″ or 3″ core
Front media path
Up to 17″ x 22″
Single sheet manual feeder, designed for fine art paper and media up to 1.3 mm thick
Borderless Sizes: 3.5″ x 5″, 4″ x 6″, 5″ x 7″, 8″ x 10″, A4 (8.3″ x 11.7″), letter (8.5″ x 11″), 11″ x 14″, 12″ x 12″, B (11″ x 17″), A3 (11.7″ x 16.5″), Super B (13″ x 19″) and C (17″ x 22″) sizes
Ink
Ink Type: Ink Type: Pigment-based Epson UltraChrome® HD ink technology
Ink Palette: 8-color Photo or Matte Black, Cyan, Vivid Magenta, Yellow, Light Cyan, Vivid Light Magenta, Light Black, Light Light Black
Ink Configuration:
Auto-Switching Black Ink Technology
Fully automatic switching between Black ink modes
Ink used during conversion
Matte to Photo Black approx. 4.6 ml
Photo to Matte Black approx. 1.6 ml
See Note1
Replacement Ink:
Epson Intelligent Ink Cartridges
Cartridge fill volume: 80 ml each color x 9 colors total
Ink cartridge shelf life
2 years from printed production date or 6 months after opened
See Note2
Connectivity
Interface:
Hi-Speed USB 2.0 (1 port)
100Base-T Ethernet (1 port)
Wi-Fi CERTIFIED™ (802.11n only)3
Wi-Fi Direct3
Epson Connect™4: Epson iPrint™ Mobile App, Apple® Airprint™, Google Cloud Print™
General P800
Operating Systems:
Windows® 8.1 (64-bit, 32-bit), Windows 7 (64-bit, 32-bit)
Mac OS® X 10.10.x, 10.9.x, 10.8.x, 10.7.x
Printer Language: Epson ESC/P2®2 raster photographic drivers standard
Temperature:
Operating
50° to 95° F (10° to 35° C)
Storage
-4° to 104° F (-20° to 40° C)
Humidity:
Operating
20% to 80% (no condensation)
Storage
5% to 85% (no condensation)
Sound Level: Approx. 50 dB according to ISO 7779
Rated Voltage: AC 110 – 120V
Rated Frequency: 50 – 60 Hz
Rated Current: Less than 1.0 A/110 – 120 V
Power Consumption:
Printing: Approx. 21 W
Sleep Mode: Approx. less than 1.8 W
Safety Standards: UL1950, CSA 22.2 950 FDA, EMI: FCC Part 15 subpart B class B, CSA C108.8 class B, AS/NZS 3548 class B
Dimensions: 26.93″(W) x 14.80″(D) x 9.85″(H)
Weight: 43 lb
P800 Notes
* Print times are based upon print engine speeds only. Total throughput depends upon front-end driver/RIP, file size, printing resolution, ink coverage, network speed etc. Print speeds are shown in min:sec. All times are in HS = High-Speed Bi-Directional Print Mode, with Normal = 1440 x 720 dpi and Max Quality = 2880 x 1440 dpi. Tests conducted by Epson America, Inc. as of April 2015
1 Ink used in conversion varies based on temperature, humidity and other factors.
2 Cartridge yields vary considerably for reasons including images printed, print settings, temperature and humidity. Yields may be lower when printing infrequently or predominantly with one ink color. A variable amount of ink remains in the cartridge after the “replace cartridge” signal. Part of the ink from the first cartridges is used for priming the printer. Ink is used for both printing and print head maintenance. All inks are used for both black and color printing. For more information about cartridges, see www.epson.com/cartridgeinfo
3 WiFi CERTIFIED™ level of performance subject to the range of the router being used. WiFi Direct may require printer software.
